6. When the dot pattern appears, press the button at the bottom of
the monitor. This activates the I MAGE S ETUP procedure, which will
optimize the display settings with the provided dot-patterns.
The screen will momentarily turn black while auto adjustment proceeds.
7. When finished, the Image Setup message disappears and the screen
returns to a normal display.
8. To clear the Image Setup test pattern, press the ESC key on your
keyboard.
You have completed the monitor setup for Windows. If you are using the
DOS operating system, go to Image Setup for DOS on page 13.
14 14
To set up the monitor automatically in Windows 95, Windows 98, Windows
NT, Windows 2000, Windows Me or Windows XP, do the following:
1. Turn on the monitor first; then turn on the computer.
If the message CHECK SIGNAL CABLE is displayed, or if nothing is
displayed, check:
• that the video interface cable is not connected properly.
• the correct video adapter card is not installed.
• the correct supported display mode is selected for your computer.
2. Wait approximately 15 minutes, until the monitor warms up.
3. Drag the icon bar and tool bar, if they are displayed, to the bottom of
the screen.
4. Insert the User's Guide and Installation Files CD into the computer CD-
ROM drive.
5. Check the operating system installed on your computer and follow the
instructions from the table below.
i If the monitor is in standby
mode (STANDBY ON), it
may automatically turn off while
you are waiting for it to warm up.
i The size and diversity of the
dot pattern varies with the
screen resolution.
Step1
Select
START
Select
RUN
Type E:\TESTPAT (change the
drive letter to match your CD-ROM
drive if it is not drive D) and press
ENTER
Step2 Step3
Operating
System
Image Setup for Windows 95, Windows 98, Windows NT, Windows 2000,
Windows Me or Windows XP
Operating system installation steps
Windows 95,
Windows 98,
Windows 2000,
Windows NT,
Windows Me or
Windows XP
