ASUS CUSL2K User’s Manual

3. HARDWARE SETUP

Layout Contents

3. H/W SETUP

19) ACHA

p.38 Chassis Intrusion Connector (2 pins)

20) WOL_CON

p.39 Wake-On-LAN Connector (3 pins)

21) WOR_CON

p.39 Wake-On-Ring Connector (2 pins)

22) LCDTV

p.40 LCD-TV Headers (18-1 pins/18 pins)

23) USB2, USB56

p.40 USB Headers (5-1 pins, 5 pins)

24) ATXPWR

p.41 ATX Power Supply Connector (20 pins)

25) JTPWR

p.41 Power Supply Thermal Sensor Connector (2 pins)

26) PWRLED (PANEL)

p.42 System Power LED Lead (3-1 pins)

27) KEYLOCK (PANEL)

p.42 Keyboard Lock Switch Lead (2 pins)

28) SPEAKER (PANEL)

p.42 System Warning Speaker Connector (4 pins)

29) MSG.LED (PANEL)

p.42 System Message LED (2 pins)

30) SMI (PANEL)

p.42 System Management Interrupt Switch Lead (2 pins)

31) PWRSW (PANEL)

p.42 ATX Power / Soft-Off Switch Lead (2 pins)

32) RESET (PANEL)

p.42 Reset Switch Lead (2 pins)
