18
English
Gives the list of options available for each item
Return to Optimized default values (not applicable to main
setup screen)
Enters BIOSNow! feature
Displays system information
Saves settings and exits setup
3.2. Standard CMOS Features
ø Includes the settings for items such as date, time, floppy disk drive specifications, and
hard drives connected to the IDE interface.
n Date (mm:dd:yy)
Allows you to setup the date in the mm:dd:yy fashion.
n Time (hh:mm:ss)
Allows you to set up the date in the hh:mm:ss fashion. The time must be entered in the
24-hour format.
n IDE Channel 0 Master(Slave) [IDE Device Setup]
IDE HDD Auto-Detection Press "Enter" to select this option for automatic device
detection.
IDE Channel 0 Master(Slave) You can use one of three methods:
Auto Allows BIOS to automatically detect IDE devices during POST(default)
None Select this if no IDE devices are used and the system will skip the
automatic detection step and allow for faster system start up.
Manual User can manually input the correct settings
Access Mode Use this to set the access mode for the hard drive. The four
options are:CHS/LBA/Large/Auto(default:Auto)
n IDE Channel 2 Master(Slave)
[IDE Device Setup]
IDE HDD Auto-Detection Press "Enter" to select this option for automatic device
detection.
CMOS Setup Utility-Copyright (C) 1984-2005 Award Software
Standard CMOS Features
Date (mm :d d:y y) Fri, Jan 9 2005
Time (hh:mm :ss) 22:31:24
} IDE Channel 0 Master [Non e]
} IDE Channel 0 Slave [Non e]
} IDE Channel 2 Master
[Non e]
} IDE Channel 2 Slave [Non e]
Drive A [1.44M, 3.5"]
Drive B [None]
Floppy 3 Mode Support [Disabled]
Halt On [All, But Keyboard]
Base Memory 640K
Extended Memory 127M
Total Memory 128M
higf: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level}
Change the day, month,
year
Sun. to Sat.
Jan. to Dec.
1 to 31 (or maximum
allowed in the month)
1999 to 2098
