Chassis / Blades / Management Module Compatibility
Blade Servers
BCS
BCE
BCH
BCHT
3
HS20 single/dual-core (8832/8843)
Yes Yes Yes Yes Yes
HS21 dual-core (8853)
Yes Yes
Up to 65W
processor power
draw
Yes Up
to
80W
HS21 quad-core (8853)
Yes
Up to 80W
Up to 7 blades
at 80W
Yes
Up to 10 at
HS21 XM dual-core (7995)
Yes
Up to 80W Up
to
65W Yes Up
to
80W
HS21 XM quad-core (7995)
Yes
Up to 80W
Up to 7 blades
at 80W
Yes
Up to 12 at
80W
HS40 single-core (8839)
No
Yes
No
Yes No
LS20 single/dual-core (8850)
Yes Yes Yes Yes Yes
LS21 dual-core (7971)
Yes
Up to 68W
Up to 68W Yes
Yes
LS41 dual-core (7972)
Yes
Up to 68W
6
Up to 68W Yes
Yes
JS20 dual-core (8842)
No
Yes Yes Yes Yes
JS21 dual-core (8844)
Yes
Yes Yes Yes Yes
QS20 multi-core (0200-AC1)
No
Yes No No
No
QS21 multi-core (????-????)
No
No
No
Yes Yes
Management Modules
MM (original Management Module)
No
Yes
No
No No
AMM (Advanced Management Module)
Yes Yes
No
Yes Yes
cMM (Advanced Management Module for
Telecom)
No
No
Yes
No No
Yes = Full density
I/O Module Compatibility by Chassis and MSIM
P/N
I/O Module
BCS
BCE
BCT
BCH
BCHT
MSIM
Ethernet
32R1892
Cisco Systems Intelligent Gb Ethernet Switch
No
Yes
Yes
Yes
Yes
1
32R1888
Cisco Systems Intelligent Gb Fiber Ethernet Switch
No
Yes
Yes
Yes
Yes
1
39Y9267
Nortel 10G Ethernet Switch Module for IBM
BladeCenter
No No No
Yes
Yes
3
32R1783
Nortel 10G Uplink Ethernet Switch
Yes
Yes
Yes
Yes
Yes
1
32R1859
Nortel Layer 2-7 Gb Ethernet Switch
No
Yes
Yes
Yes
Yes
3
32R1860
Nortel Layer 2/3 Copper Gb Ethernet Switch
Yes
Yes
Yes
Yes
Yes
1
2
Non-NEBS environment.
3
If fully configured, must leave 1 slot open in power domain 1.
4
When fully configuring a BladeCenter E (8677) chassis with the maximum possible HS21 XM blade server configuration (fourteen HS21 XM
blade servers, each with two 80W processors, eight 4GB memory DIMMs, one SAS HDD, one USB-based flash drive, one I/O card and one
cKVM card), there could be periods of time that Power Domain 2 exceeds the 13.5amp rating guidance (Power Domain 1 will not exceed the
rating guidance). While this is not violating any safety rules, we recommend that your clients review the electrical infrastructure and power
distribution of their installations to account for a peak of 14.4A.
5
95W is supported but will throttle performance to fit in power envelope – recommend using in BladeCenter H or HT.
