BladeCenter HT Chassis Specifications
# of mouse ports None (USB-attach)
# of keyboard ports None (USB-attach)
# of USB 2.0 ports Up to 6 (2 in Advanced Management Module, 2 per Media Tray)
# of video ports 1 (in Advanced Management Module)
Light path diagnostic panel Yes (in Media Tray)
Predictive Failure Analysis support
Blades, bridge/switch modules, I/O modules, management modules, power modules,
fan modules, media tray
Power supply size standard
2535W DC (8740-1RX), -48V or -60V (nominal);
2880W AC (8750-1RX) at 208V; 3160W at 240V
# of power supplies standard /
maximum
2 / 4
Heat output 4270 BTUs/hr (1250 watts) min., to 21,850 BTUs/hr (6400 watts) max.
# of fan modules standard / max. 4 / 4
Dimensions (HWD) / weight
21.0” (528mm) H
17.4” (442mm) W
25.4” (645mm) D
27.8” (706 mm) D (with deep bezel)
150-350 lb
62.8-159 kg
Extended/long life support 3 years production from date of GA; 5 years post-production support (standard)
Length of limited warranty 3 years (parts and labor) onsite
Chassis Side-by-Side Comparison
SMB Chassis Enterprise Chassis Telecom Chassis
Chassis name BladeCenter S BladeCenter E BladeCenter H BladeCenter T BladeCenter HT
Rack form factor 7U 7U 9U 8U 12U
Supports deskside
use
Yes (with
optional Office
Enablement Kit)
Rack-only Rack-only Rack-only Rack-only
# of blades
supported
6 x 30mm /
3 x 60mm /
2 x 90mm /
1 x 120mm 14 x 30mm /
7 x 60mm /
4 x 90mm /
3 x 120mm
14 x 30mm /
7 x 60mm /
4 x 90mm /
3 x 120mm
8 x 30mm /
4 x 60mm /
2 x 90mm /
2 x 120mm 12 x 30mm /
6 x 60mm /
4 x 90mm /
3 x 120mm
Blade types
supported
HC10, HS12.
HS20, HS21,
HS21 XM, JS12,
JS21, JS22,
LS20, LS21
HC10, HS12.
HS20, HS21, HS21
XM, HS40, JS12,
JS20, JS21, LS20,
LS21, LS41, QS20
HC10, HS12.
HS20, HS21, HS21
XM, HS40, JS20,
JS21, JS22, LS20,
LS21, LS41, QS21,
QS22
HC10, HS20, HS21,
HS21 XM, JS12,
JS20, JS21, LS20,
LS21, LS41
HC10, HS20, HS21,
HS21 XM, JS20,
JS21, JS22, LS20,
LS21, LS41, QS21,
QS22
Fabric bandwidth 1GB 1GB 10GB 1GB 10GB
# of management
modules std / max.
1 / 1
1 / 2
hot-swap/
redundant with 2
installed
1 / 2
hot-swap/
redundant with 2
installed
1 / 2
hot-swap/redundant
with 2 installed
1 / 2
hot-
swap/redundant
with 2 installed
# of power modules
std / max
2 / 4
hot-
swap/redundant
(110V = N+1,
220V = N+N)
2 / 4
hot-
swap/redundant
(N + N)
2 / 4
hot-
swap/redundant
(N + N)
2 / 4
hot-swap/redundant
(N + N)
2 / 4
hot-
swap/redundant (N
+ N)
Power module size 1450W AC 2000W AC 2900W AC 1300W 1300W 2535W 2880W
Please see the Legal Information section for important notices and information. 26.
