INSTALLATIONS
MB865 User’s Manual
5
Installations
This section provides information on how to use the jumpers and
connectors on the MB865 in order to set up a workable system. The
topics covered are:
Installing the CPU........................................................................ 6
ATX Power Installation ............................................................... 6
Installing the Memory .................................................................. 7
Setting the Jumpers ...................................................................... 8
Connectors on MB865 ............................................................... 12
Watchdog Timer Configuration ................................................. 24
