Integra DTR-7.8 - Manual (Page 127)

127
Specifications
Amplifier Section
Video Section
Tuner Section
■ FM
■
AM
■ Digital Tuner
General
■
Video Input
■ Video Output
■ Audio Inputs
■
Audio Outputs
■
Control Terminal
Specifications and features are subject to change without
notice.
Rated Output Power
North American:
130 watts minimum continuous power per channel, 8 ohm
loads, 2 channels driven from 20 Hz to 20 kHz, with a
maximum total harmonic distortion of 0.08% (FTC)
150 watts minimum continuous power per channel, 8 ohm
loads, 2 channels driven at 1 kHz, with a maximum total
harmonic distortion of 0.7% (FTC)
160 watts minimum continuous power per channel, 6 ohm
loads, 2 channels driven at 1 kHz, with a maximum total
harmonic distortion of 0.1% (FTC)
Australian:
7 ch
×
180 W at 6 ohms, 1 kHz, 1 ch driven (IEC)
Maximum Output Power
Asian:
7 ch
×
230 W at 6 ohms, 1 kHz, 1 ch driven (JEITA)
Dynamic Power 300 W (3 Ω , Front)
250 W (4 Ω , Front)
150 W (8 Ω , Front)
THD (Total Harmonic
Distortion)
0.05% (Power Rated)
Damping Factor 60 (Front, 1 kHz, 8 Ω )
Input Sensitivity and
Impedance
200 mV/ 47 k Ω (LINE)
2.5 mV/47 k Ω (PHONO MM)
Output Level and
Impedance
200 mV/ 470 Ω (REC OUT)
Phono Overload 70 mV (MM 1 kHz, 0.5%)
Frequency Response 5 Hz–100 kHz/ +1 dB–3 dB (Direct mode)
Tone Control ±10 dB, 20 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 110 dB (LINE, IHF-A)
80 dB (PHONO, IHF-A)
Speaker Impedance 4 Ω –16 Ω
Input Sensitivity/Output
Level and Impedance
1 Vp-p /75 Ω (Component and S-Video Y)
0.7 Vp-p /75 Ω (Component Pb/Cb,Pr/Cr)
0.28 Vp-p /75 Ω (S-Video C)
1 Vp-p /75 Ω (Composite)
Component Video
Frequency Response
5 Hz – 100 MHz, –3 dB
Tuning Frequency Range
North American: 87.5 MHz– 107.9 MHz
Australian: 87.5 MHz– 108.0 MHz
Tuning Frequency Range
North American: 530 kHz–1710 kHz
Australian: 522 kHz–1611 kHz
North American: XM, SIRIUS
Preset Channel 40
Power Supply AC 120 V, 60 Hz
AC 220-240 V, 50/60 Hz
Power Consumption
North American: 9.5 A
Australian: 870 W
Dimensions
(W
×
H
×
D)
435
Ч
194
Ч
454.5 mm
17-1/8"
Ч
7-5/8"
Ч
17-7/8"
Weight
North American: 23.1 kg
50.9 lbs.
Australian: 22.8 kg
50.3 lbs.
HDMI IN 1, IN 2, IN 3
Component IN 1 (DVD), IN 2, IN 3
Composite AUX 1, GAME/TV, CBL/SAT,
VCR/DVR, DVD, AUX 2
S-Video AUX 1, GAME/TV, CBL/SAT,
VCR/DVR, DVD, AUX 2
HDMI OUT
Component MONITOR OUT 1, MONITOR OUT 2
Composite VCR/DVR OUT, MONITOR OUT
S-Video VCR/DVR OUT, MONITOR OUT
Digital Inputs COAXIAL (IN 1, IN 2, IN 3),
OPTICAL (IN 1, IN 2), DIGITAL
Analog Inputs PHONO, CD, TAPE, AUX 1, GAME/TV,
CBL/SAT, VCR/DVR, DVD, MULTI CH
(FRONT, CENTER, SUBWOOFER,
SURR, SURR BACK), AUX 2
Multichannel Inputs 7.1 ch
Digital Output OPTICAL (OUT)
Analog Outputs TAPE, VCR/DVR, PRE OUT (FRONT,
CENTER, SUBWOOFER, SURR, SURR
BACK, ZONE 2, ZONE 3)
Multichannel Pre
Outputs
7
Subwoofer Pre Outputs 1
Speaker Outputs
ZONE2 R, SURR BACK R, FRONT R,
SURR R, CENTER, SURR L, FRONT L,
SURR BACK L, ZONE2 L
Phones PHONES
MIC Yes
RS232 1
Ethernet 1
IR Input/Output 2/1
12 V Trigger Out 3
USB No
