Warning – InFocus SP-CEIL-UNIV User Manual
Page 10
ISSUED: 10-22-04 SHEET #: 055-9236-5 01-10-06
Visit the InFocus Web Site at www.infocus.com
10 of 11
Slide connection block with projector into projector mount
assembly (A) as shown. Tighten captive screw to secure
projector to projector mount assembly (A).
IMPORTANT: For security installations, insert
one #10-32 x 1/4" socket pin screw (D) through
projector mount assembly (A) and into connection
block as shown.
A
CONNECTION BLOCK
D
CONNECTION BLOCK
A
CAPTIVE SCREW
FRONT OF MOUNT
• Always use an assistant or mechanical lifting equipment to safely lift and position the projector.
WARNING
J. IN72, IN74, IN76
K.
IN24, IN26
*
R
*
R
