Figure 4.1 – Invacare BAR750 User Manual
Page 24
SECTION 4—PACKAGING, HANDLING AND SET-UP
24
FIGURE 4.1 Assembling the Bed
DETAIL “A”
DETAIL “B”
DETAIL “C”
DETAIL “D”
DETAIL “E”
DETAIL “F”
DETAIL “G”
DETAIL “H”
Packing
Bands
Casters
Clevis
Pin
Clevis
Pin
Head Section
Foot Section
Side
Frame
Holes
Side
Frame
Hole
Clevis Pin
Hairpin Clip
Frame Section
Actuator
Support
Leg
Lock
Pin
