Chapter 5 Using the Command-Line Interface 85
▼ Adding ICP rules
1 Select the config menu, and press Enter.
2 Select routing, and press Enter.
3 Select icp, and press Enter.
4 Select rules, and press Enter.
5 Select add rules, and press Enter.
6 Add an ICP rule, and press Enter.
7 Press CTRL-X to save your rule and return to the previous screen.
Each rule must contain the name and configuration information for a
single ICP peer in the following format:
The following table describes each field:
host:hostIP:cache_type:proxy_port:icp_port:MC_on:MC_IP:MC_TTL:
Field Description
host The host name of the ICP peer. The name
localhost is reserved for the appliance.
host IP The IP address of the ICP peer.
cache_type The cache type. Use the following options:
❚ 1 to indicate an ICP parent cache
❚ 2 to indicate an ICP sibling cache
Option 3 is reserved for the local host (the
appliance itself).
proxy_port The port number of the TCP port used by the
ICP peer for proxy communication.
icp_port The port number of the UDP port used by the
ICP peer for ICP communication.
MC_on Multicast on/off. Use the following options:
❚ 0 if multicast is not enabled
❚ 1 if multicast is enabled
