PARTS LIST
KEY NO. DESCRIPTION Q’ty
1 Upright
Beam 2
2 Cross Brace 1
3 Main Seat Support 1
4 Front Stabilizer 1
5 Leg Developer Holder 1
6 Backrest Support 2
7 Backrest Incline Support 1
8 Backrest Adjustment Bar 1
9 Arm Curl Stand 1
10 Crutch 2
11 Weight Post 2
12 Foam Tube 3
13 Seat Bracket 1
14 Leg Developer 1
15 Curl Bar Handle Support 1
16 Curl Bar Handle 1
17 Backrest Board 1
18 Seat 1
19
Arm Curl Pad 1
20 Seat Incline Adjustment 1
21 4 ¾” x 2” Bracket 3
22 Bushing 2
23 4” L-shaped Pin 2
24 3” L-shaped pin 1
25 Spring Clip 3
26 2 3/8” x 2” Crutch Sleeve 2
27 2” x 1 ¾” Sleeve 1
28 2 3/8” Square End Cap 4
29 2” Square End Cap 2
30 1 5/8” x 2 3/8” End Cap 2
31
∅
1” Cone-shaped End Cap 2
32 Foam Roll End Cap 6
33
∅
1” End Cap 1
34 1” Square End Cap 3
35
∅
1 1/8” x 1” End Cap 2
36 Olympic Sleeve 3
37 Foam Roll 6
38 Lock Knob 3
39 Axle 1
40
∅
2 3/8” Axle Bushing 2
41
∅
1 3/8” Spacer 2
42 Curl Bar Handle Grip 2
43 M10 x 7 ¼” Allen Bolt 1
44 M10 x 3 1/8” Carriage Bolt 4
45 M10 x 2 ¾” Carriage Bolt 5
46 M10 x 1” Allen Bolt 2
47 M10 x 5/8” Allen Bolt 5
48 M8 x 5/8” Allen Bolt 2
49 M6 x 1 3/8” Hex Bolt 4
50 M6 x 5/8” Hex Bolt 4
51 M10 Aircraft Nut 10
52
∅
¾” Washer 18
53
∅
5/8” Washer 2
54
∅
½” Washer 8
55 M8 x ½” Allen Screw 3
