Rear View
1. Firmware Upgrade Port
2. DC Power Jack
3. Console USB Mouse Port
4. Console USB Keyboard Port
5. USB 2.0 Peripheral Sharing Port
6. Console Mic. Port
7. Console HDMI Video Port
8. Console Analog Audio Port 9. CPU2 Mic. Port
10. CPU2 Analog Audio Port
11. CPU2 HDMI Video Port
12. CPU2 USB Port
13. CPU1 Mic. Port
14. CPU1 Analog Audio Port
15. CPU1 HDMI Video Port
16. CPU1 USB Port
1 9 13 10 14 12 16 3 6 8 4 5 7 11 15 2
