Upgrade Fail
If you don’t see “Firmware upgrade OK” in the “Status Messages” window, it means the utility has failed to
complete the firmware successfully. If that occurs, please do the following:
Step 1
Unplug the DC connector from the KVM, then
remove the housing of the KVM.
Step 2
Using a jumper cap, short the jumper on the main
board labeled J11 (for GCS1792) / J17
(for GCS1794).
GCS1792
GCS1794
