Using the Setup Program
55
Table 14. Peripheral Configuration Submenu (continued)
Feature Options Description
Parallel Port
•
Disabled
•
Enabled
•
Auto (default)
Configures the parallel port.
Auto assigns LPT1 the address 378h and the
interrupt IRQ7.
An * (asterisk) displayed next to an address indicates a
conflict with another device.
Mode
•
Output Only
•
Bi-directional
(default)
•
EPP
•
ECP
Selects the mode for the parallel port. Not available if the
parallel port is disabled.
Output Only operates in AT † -compatible mode.
Bi-directional operates in PS/2-compatible mode.
EPP is Extended Parallel Port mode, a high-speed
bi-directional mode.
ECP is Enhanced Capabilities Port mode, a high-speed
bi-directional mode.
Base I/O Address
(This feature is present
only when Parallel Port
is set to Enabled)
•
378 (default)
•
278
•
228
Specifies the base I/O address for the parallel port.
Interrupt
(This feature is present
only when Parallel Port
is set to Enabled)
•
IRQ 5
•
IRQ 7 (default)
Specifies the interrupt for the parallel port.
DMA Channel
(This feature is present
only when Parallel Port
Mode is set to ECP)
•
1
•
3 (default)
Specifies the DMA channel.
Audio Device
•
Disabled
•
Enabled (default)
Enables or disables the onboard audio subsystem.
LAN Device
(This feature is present
only when there is
onboard LAN)
•
Disabled
•
Enabled (default)
Enables or disables the LAN device.
Legacy USB Support
•
Disabled
•
Enabled (default)
Enables or disables USB legacy support.
