Connecting the Processor Fan Heatsink Cable
Connect the processor fan heatsink cable to the processor fan connector (see Figure 10).
OM12083
Figure 10. Connecting the Processor Fan Heatsink Cable to the Processor Fan Connector
Removing a Processor
For instruction on how to remove the processor fan heatsink, refer to the processor installation
manual or the Intel World Wide Web site at:
✏
NOTE
Once removed, the processor fan heatsink base push pins cannot be reused.
