SECTION 14—SCOOTER ACCESSORIES
66
INSTALLING/REMOVING THE SAFETY FLAG
NOTE: For this procedure, refer to FIGURE 14.3.
ƽ WARNING
The installation of the safety flag onto the back of the scooter seat significantly
increases the length of the scooter. When turning the scooter or swiveling the
scooter seat, it is important to take note of this increased length - otherwise, injury
and/or damage to the surrounding property may result.
INSTALLING
1. Install the bracket into the accessory tube located on the back of the seat.
2. Install mounting knob to secure the bracket in place. Securely tighten.
3. Install safety flag into bracket.
REMOVING
1. Remove the safety flag from the
bracket.
2. Remove the mounting knob that
secures the bracket in place.
3. Remove the bracket from the accessory
tube located on the back of the seat.
FIGURE 14.3 - INSTALLING/
INSTALLING/REMOVING/USING THE WALKER
HOLDER
ƽ INSTALLATION WARNINGS
After ANY adjustments, repair or service and BEFORE use, make sure that all
attaching hardware is tightened securely.
The installation of the walker holder onto the back of the scooter seat significantly
increases the length of the scooter. When turning the scooter or swiveling the
scooter seat, it is important to take note of this increased length - otherwise, injury
and/or damage to the surrounding property may result.
Seat
Accessory Tube
Mounting Knob
Bracket
Safety Flag
