PARTS LIST
KEY NO. DESCRIPTION QUANTITY
1 Right Upright Beam 1
2 Left Upright Beam 1
3 Main Seat Support 1
4 Cross Brace 1
5 Front Leg 1
6 Arm Curl Stand 1
7 Leg Developer 1
8 Weight Post 2
9 Arm Curl Handle 1
10 Main Seat Stabilizer 1
11 Arm Curl Handle Bar 1
12 Backrest Support 2
13 Foam Tube 2
14 Curved Bracket 2
15 L-shaped Lock Pin 1
16 Lock Knob 1
17 Arm Curl Handle Grip 2
18 Rubber Bumper 1
19 Ø 1 ½” Bushing 2
20 2 3/8” Rubber Bumper 2
21 Ø 1 ¼” Bushing 2
22 1” Square End Cap 2
23 Ø 1” End Cap 8
24 Upright End Cap 2
25 Ø ¾” Bushing 2
26 Spring Clip 3
27 Front Leg End Cap 1
28 Ø 2 3/8” x Ø 2” Sleeve 1
29 Ø 2” End Cap 3
30 Ø 1” Con-shaped End Cap 2
31 Foam Roll 4
32 Arm Curl Pad 1
33 Seat Pad 1
34 Backrest Board 1
35 Backrest Adjustment Bar 1
36 M10 x 3 1/8” Carriage Bolt 4
37 M10 x 2 ½” Carriage Bolt 2
38 M8 x 5/8” Allen Bolt 6
39 M8 x 3 1/8” Allen Bolt 1
40 M10 x 1” Allen Bolt 2
41 M6 x 1 ½” Hex Bolt 8
42 M6 x ¾” Philips Screw 1
43 Ø ¾” Washer 6
44 Ø 5/8” Washer 8
45 Ø ½” Washer 8
46 Curved Washer 2
47 ST5 Screw 2
48 M10 Aircraft Nut 6
49 M8 Aircraft Nut 1
