Impex WM-357 User Manual
Competitor weight bench wm-357, Model wm-357, Impex

NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Identifier
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
WM-357
Retain This
Manual for
Reference
06-26-06
OWNER'S
MANUAL
COMPETITOR
WEIGHT BENCH
WM-357
IMPEX
®
INC.
14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746
Tel: (800) 999-8899 Fax: (626) 961-9966
Table of contents
Document Outline
- BEFORE YOU BEGIN...................................................................................…. 1
- IMPORTANT SAFETY NOTICES..................................................................…. 2
- HARDWARE IDENTIFIER.....…....................................................................…. 4
- ASSEMBLY INSTRUCTIONS........................................................................…. 5
- EXPLODED DIAGRAM………………………………………………………………. 10
- PARTS LIST...............................................................................................……. 11
- WARRANTY.................................................................................................…. 12
- ORDERING PARTS.......................................................................................… 12
- ASSEMBLY INSTRUCTION
- Attach the Leg Developer (#7) to the Front Leg (#5). Secure it with one M8 x 3 1/8” Allen Bolt (#39), two Ø 5/8” Washers (#44), and one M8 Aircraft Nut (#49).
- Insert two Foam Tubes (#13) halfway through the holes on the Leg Developer. Push four Foam Rolls (#30) onto the Tubes from both sides.
- Place a Spring Clip (#26) onto the weight post on the Leg Developer. The maximum weight capacity for Leg Developer is 100 lbs.
- Attach the Backrest Supports (#12) onto both ends of the pivot on the Main Seat Support (#3). Place the other end rest against the Backrest Adjustment Bar (#35).
- Place the Backrest Board (#34) onto the Backrest Supports. Secure it with four M6 x 1 ½” Hex Bolts (#41) and Ø ½” Washers (#45).
- Place the Seat Pad (#33) onto the Main Seat Support. Secure it with four M6 x 1 ½” Hex Bolts (#41) and Ø ½” Washers (#45).
- Attach the Arm Curl Pad (#32) to the Arm Curl Stand (#6). Secure it with two M8 x 5/8” Allen Bolts (#38) and Ø 5/8” Washers (#44).
- Insert the Arm Curl Stand into the top opening on the Front Leg. Secure it with a Lock Knob (#16).
- 1 Right Upright Beam 1
- 19 Ø 1 ½” Bushing 2
- 20 2 3/8” Rubber Bumper 2
- 21 Ø 1 ¼” Bushing 2
