- 28 - 8S661FXM-RZ Motherboard
English
Onboard LAN device
Enabled Enable Onboard LAN function. (Default value)
Disabled Disable this function.
USB Controller
Enabled Enable USB Controller. (Default value)
Disabled Disable USB Controller.
USB Legacy Support
Enabled Enable USB Legacy Support.
Disabled Disable USB Legacy Support. (Default value)
Onboard Serial Port 1
Disabled Disable onboard Serial port 1.
3F8/IRQ4 Enable onboard Serial port 1 and address is 3F8. (Default value)
2F8/IRQ3 Enable onboard Serial port 1 and address is 2F8.
3E8/IRQ4 Enable onboard Serial port 1 and address is 3E8.
2E8/IRQ3 Enable onboard Serial port 1 and address is 2E8.
Auto BIOS will automatically setup the port 1 address.
Onboard Serial Port 2
Disabled Disable onboard Serial port 2
3F8/IRQ4 Enable onboard Serial port 2 and address is 3F8.
2F8/IRQ3 Enable onboard Serial port 2 and address is 2F8. (Default value)
3E8/IRQ4 Enable onboard Serial port 2 and address is 3E8.
2E8/IRQ3 Enable onboard Serial port 2 and address is 2E8.
Auto BIOS will automatically setup the port 2 address. .
Onboard Parallel port
Disabled Disable onboard LPT port.
378/IRQ7 Enable onboard LPT port and address is 378/IRQ7. (Default Value)
278/IRQ5 Enable onboard LPT port and address is 278/IRQ5.
3BC/IRQ7 Enable onboard LPT port and address is 3BC/IRQ7.
Parallel Port Mode
SPP Use Parallel port as Standard Parallel Port.
EPP Use Parallel port as Enhanced Parallel Port.
ECP Use Parallel port as Extended Capabilities Port. (Default Value)
ECP+EPP Use Parallel port as ECP & EPP mode.
ECP Mode Use DMA
This feature allows you to select Direct Memory Access(DMA) channel if the ECP mode selected.
1 Set ECP Mode Use DMA to 1.
3 Set ECP Mode Use DMA to 3. (Default value)
