- 23 - BIOS Setup
English
Standard CMOS Features
Date
The date format is , , , .
Week From Sun. to Sat., determined by the BIOS and for display only.
Month From Jan. to Dec.
Day From 1st to 31st (or the maximum allowed in the month)
Year From Year 1999 to 2098
Time
The times format in . The time is calculated based on the 24-hour
military-time clock. For example, 1 p.m. is displayed as 13:00:00.
IDE Primary Master, Slave / IDE Secondary Master, Slave
The category identifies the types of hard disk from drive C to F that has been installed in the
computer. There are two types: auto type, and manual type. Manual type is user-definable; Auto type
automatically detects HDD type.
Note that the specifications of your drive must match with the drive table. The hard disk will not work
properly if you enter improper information for this category.
If you select User Type, related information will be asked to enter to the following items. Enter the
information directly from the keyboard and press . Such information should be provided in the
documentation form your hard disk vendor or the system manufacturer.
Cylinder Number of cylinders
Head Number of heads
Precomp Write precomp
Landing Zone Landing zone
Sector
Number of sectors
If a hard disk has not been installed, select NONE and press .
CMOS Setup Utility-Copyright (C) 1984-2004 Award Software
Standard CMOS Features
Date (mm:dd:yy) Fri , Jan 9 2004
Time (hh:mm:ss) 22:31:24
} IDE Primary Master [None]
} IDE Primary Slave [None]
} IDE Secondary Master [None]
} IDE Secondary Slave [None]
Drive A [1.44M, 3.5"]
Drive B [None]
Floppy 3 Mode Suport [Disabled]
Halt On [All, But Keyboard]
Base Memory 640K
Extended Memory 127M
Total Memory 128M
higf: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Save Defaults F7: Optimized Defaults
Item Help
Menu Level }
Change the day, month,
year
Sun. to Sat.
Jan. to Dec.
1 to 31 (or maximum
allowed in the month)
1999 to 2098
