Paper Weight
Multi-part forms with carbon (max. 2 copies)
First/last sheet 17.50-20.00 lbs (70-80g/²)
Copies 8.75-10.00lbs (35-40g/²)
Carbon approx. 6.25 lbs (25g/²)
Note The uncoated surface of the carbon paper has to be rough.
Pressure-sensitive multi-part forms (max. 2 copies)
First/last sheet 17.50-20.00 lbs (70-80g/²)
Copies 10.00-15.00 lbs (40-60g/²)
Table A–1 Technical Data
Physical Dimensions: Height: 7.48" (190mm)
Depth: 11.50" (292mm)
Width: 12.75" (324mm)
Weight: 1.76lbs (0.8kgs)
Paper Bin Capacity: A maximum of 80 sheets of 20lbs (80g/m²) paper weight
Output Stacker Capacity: A maximum of 80 sheets of 20lbs (80g/m²) paper weight
Paper Dimensions: Length: max. 14" (355mm);
min. 8" (203mm)
Width: 4" to 9" (100mm to
229mm)
Weight: 16lbs-24lbs (64-96
g/m²)
Operating Temperature
Range:
50°F to 104°F
Relative Humidity: 40% to 80%
Temperature Variation: max. 15°F (8°C) per hour
Storage Temperature
Range:
-22°F to 158°F
Relative Humidity: max. 95% non-condensing
Paper Specifications and Technical Data A–3
