Section 8—front casters, Adjusting front caster height – Invacare Wheelchair Atlas User Manual
Page 27
SECTION 8—FRONT CASTERS
27
SECTION 8—FRONT CASTERS
ƽ WARNING
After any adjustments, repair or service and before use, make sure all attaching
hardware is tightened securely. Otherwise injury or damage may occur.
Adjusting Front Caster Height
ƽ WARNING
Make sure both front casters are the same size and are installed into the same
respective mounting hole before using the wheelchair. Otherwise, injury may occur.
NOTE: For this procedure, refer to FIGURE 8.1.
1. Remove the hex screw, washers and locknut that secure the front caster to the fork.
2. To reinstall the new front caster onto the fork, reverse STEP 1.
FIGURE 8.1 Adjusting Front Caster Height
Locknut
Fork
Front
Caster
Hex
Screw
NOTE: Adjustable height
fork shown.
