Page 169

Parts Catalog 135

System Assembly

Assembly 1: System Uni

Asm-

Index

FRU

Number

Description

1-1

22P2259

Main Bezel (w/ Front USB), White,
Aptiva

1-1

22P2270

Main Bezel (w/ Front USB), White,
Netvista

1-2

20L2197

3.5" FDD/HDD (Holder) Bracket

1-3

20L2193

Top Cover, White

1-4

22P2270

Main Bezel Door, White (India only)

1-4

20L2194

Main Bezel Door, White

1-5

20L2195

Drive Bay Panel, White

1-6

22P2261

Chassis Assembly, Lower Case
(without SPS) w/power supply frame,
drive frame, bracket port, w/Front USB

1-7

20L2190

Power Switch/HDD-Pwr Led Cable
Asm

1-8

19K3648

S21M - Micro ATX, Socket A, W/VIA
KZ133
