116 IBM Desktop System HMM
1 Optional output from monitor.
2 Note: The IEEE-1394 internal cable bundle
needs an outer shield to minimize internal
crosstalk within the cable construction. The outer
EMI containment shield for the IEEE-1394 func-
tion will be provided by the overall P&D cable
shield. If the internal bundle shield for IEEE-1394
is required, this may be terminated to pin #18. It
is recommended that this implementation be
evaluated in the case where both Charge Power
return and the IEEE-1394 internal cable bundle
shield will be commoned to pin #18.
P&D-D Signal Pin Assignments
Pin Signal Pin Signal
1 TMDS Data2 + 16 USB data +
2 TMDS Data2 - 17 USB data -
3 TMDS Data2 return 18 1394 outer shield
(optional) & Charge
Power return 2
4 Unused 19 1394 Vg
5 Unused 20 1394 Vp
6 Unused 21 TMDS Data0 +
7 TMDS Clock return 22 TMDS Data0 -
8
Charge power
1
+
23 TMDS Data0 return
9 1394 pair A, data - 24 Unused
10 1394 pair A, data + 25 DDC return
11 TMDS Data1 + 26 DDC data (SDA)
12 TMDS Data1 - 27 DDC clock (SCL)
13 TMDS Data1 return 28 +5 VDC
14 TMDS Clock + 29 1394 pair B, Clock +
15 TMDS Clock - 30 1394 pair B, Clock -
