An affordable dual-socket, dual- and quad-core SMP server
with high performance and data protection for small and
medium businesses
• 64-bit extensions (EM64T)
• Leading-edge front-side bus —Up to 1333MHz FSB (model-specific)
• Fast memory — Fully buffered 667MHz PC2-5300 DDR II ECC memory standard with two-
way or four-way interleaving
• Fast disk technology — Integrated Serial-Attach SCSI (SAS) controller (selected models)
and slotless hardware-based RAID controller with optional upgrade to RAID 5 controller with
256MB of battery-backed cache
• Fast communications — Integrated Gigabit Ethernet controller
• Fast I/O —PCIe x8 and x4 and PCIx/133 adapter slots
Flexibility
• Large memory capacity — Up to 32GB of fully buffered memory, using 8 DIMMs
• High-capacity disk storage — Up to 2.4TB of internal hot-swap SAS storage or 6.0TB of
hot-swap SATA II storage (using eight 3.5-inch drives), or up to 3.0TB of simple-swap
SATA II storage using four 3.5-inch drives)
• Support for an optional half-high or full-high internal tape drive (in addition to the eight
HDDs)
• High-performance external expansion — five 480Mbps USB 2.0 ports (two front, two rear,
one internal)
• Hardware-based RAID-0/1/10 support standard in hot-swap models (upgradeable to RAID-
0/1/10/1E/5/6 support); firmware-based RAID-0/1 support standard in simple-swap models
upgradeable to hardware-based RAID-8k support)
• Six available adapter slots —
Two x8
One x4
Two 133MHz PCIx slots (1GBps)
One 33MHz legacy PCI slot
• Integrated CD-ROM drive
• Optional
iSCSI HBA Adapter for IXA Connectivity (to System i
™
/iSeries
™
servers)
Manageability, Serviceability and Availability
• IBM
Director systems management software, including:
IBM Management Processor Assistant
IBM Rack Manager
IBM RAID Manager
IBM Update Assistant
IBM
Software
Distribution
IBM System Availability
• Integrated Baseboard Management Controller (BMC):
IPMI 2.0 compliance, including highly secure remote power control
Text console redirection systems management standard
• Active Memory protection:
Advanced Chipkill ECC memory protection, and either
Online hot-spare memory, or
Memory mirroring
• Support
for
highly available hardware-based RAID-1/10 arrays standard, without consuming
an adapter slot; upgradeable to RAID-1E/5/6 using a slotless card
• Hot-swap SAS, hot-swap SATA or simple-swap SATA hard disk drives
• Ultra-efficient cooling incorporating Calibrated Vectored Cooling features
• Optional hot-swap/redundant power supplies and cooling
• Light path diagnostics (front LED panel, externally viewable light path panel)
• Optional
Remote Supervisor Adapter II SlimLine daughter card (no slot required)
Supports
the
LDAP and SSL industry standards
• Optional
tower-to-rack conversion kit
11
The x8 slots can accept x1, x4 or x8 adapters running at x1, x4 or x8 throughput, respectively.
12
The x4 slot can accept x1, x4 or x8 adapters; however x8 adapters will be limited to x4 throughput.
