An affordable dual-socket, dual- and quad-core SMP server
with high performance and data protection for small and
medium businesses
x3400 Images
Front View Rear View
x3400 Specifications
Machine type
7973-2xX/2xY,4xX/4xY, AxX/AxY,
DxX/DxY, JxX/JxY, LxX/LxY
(Simple-swap 1 yr. warr.)
7974-2xX/2xY, 4xX/4xY, AxX/AxY,
DxX/DxY, JxX/JxY, LxX/LxY
(Simple-swap 3 yr. warr.)
7975-2xX/2xY, 4xX/4xY, AxX/AxY,
DxX/DxY, JxX/JxY, LxX/LxY
(Hot-swap 1 yr. warr.)
7976-2xX/2xY, 4xX/4xY, AxX/AxY,
DxX/DxY, JxX/JxY, LxX/LxY
(Hot-swap 3 yr. warr.)
Form factor Tower (convertible to 5U rack)
Processor type
Quad-core Intel Xeon
(E54xx)
2.0GHz E5405 (AxX/AxY), 2.33GHz E5410
(DxX/DxY), 2.5GHz E5420 (JxX/JxY),
2.66GHz E5430 (LxX/LxY),
Dual-core Intel Xeon
(E52xx)
1.86GHz E5205 (2xX/2xY)
Maximum processor power draw 80W (AxX/AxY, BxX/BxY, CxX/CxY, DxX/DxY, JxX/JxY, LxX/Lx, 2xX/2xY)
Front-side bus (FSB) speed 1333MHz (AxX/AxY, DxX/DxY, JxX/JxY, LxX/LxY) 1066MHz (2xX/2xY)
# of processors standard / maximum 1 / 2
Internal L2 cache
12MB (AxX/AxY, DxX/DxY, JxX/JxY,
LxX/LxY 6MB (2xX/2xY)
Chipset Intel 5000P
Standard / maximum memory 9 1GB (2 x 512MB) / 32GB
Standard memory type Fully buffered PC2-5300 (667MHz) DDR II ECC with Chipkill protection
Memory interleaving Yes (four-way using multiples of 4 DIMMs; two-way with two DIMMs)
9 Maximum memory and disk capacity may require the replacement of standard components with the largest supported component
available.
4 3.5” SAS/SATA
HDD Bays
Locking
Drive
Cover
2 Open
5.25” Drive
Bays
CD-ROM
Drive
Hexagonal
Ventilation
Holes
Cover
Lock
Cover
Latch USB 2.0
Ports
Fast Ethernet
Port for BMC
Serial
Port
Keyboard
and Mouse
Ports
Hot-Swap Power
and Fans
USB
Ports
Ethernet
Port
Video
Port
Parallel
Port
Serial
Port
Rear
Fan
Adapter
Slots
Please see the Legal Information section for important notices and information.
