Impex PL-01012RP User Manual
Impex fitness products
NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Identifier
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
PL-01012RP
Retain This
Manual for
Reference
08-29-02
OWNER'S
MANUAL
MARCY RECUMBENT BIKE
PL-01012RP
IMPEX FITNESS PRODUCTS
14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746
Tel: (800) 999-8899 Fax: (626) 961-9966
Table of contents
Document Outline
- BEFORE YOU BEGIN...................................................................................…. 1
- IMPORTANT SAFETY NOTICES..................................................................…. 2
- HARDWARE IDENTIFIER.....…....................................................................…. 3
- ASSEMBLY INSTRUCTIONS........................................................................…. 4
- EXPLODED DIAGRAM………………………………………………………………. 9
- PARTS LIST...................................................................................................…. 10 COMPUTER................................................................................................…… 11
- WARRANTY.................................................................................................…. 13
- ORDERING PARTS.......................................................................................… 13
- ASSEMBLY INSTRUCTION
- Attach the Seat Support (#28) to the Seat Post (#16). Secure it with five M8 x 5/8” Allen Bolts (#20) and ( 5/8” Washers (#21).
- Attach the Handlebar (#25) to the Seat Support (#28). Secure it with two M8 x 2 ¾” Hex Bolts (#26), four ( 5/8” Washers (#21) and two M8 Nylon Nuts (#27).
- Attach the Backrest Board (#29) to the Seat Support (#28). Secure it with four M8 x 5/8” Allen Bolts (#20).
- Place the Seat Pad (#30) onto the Seat Support (#28). Secure it with two M8 x 5/8” Allen Bolts (#20).
- Thread the Left & Right Pedals (#14) & (#15) onto the Crank (#32).
- PARTS LIST
- Maintenance and Storage
- COMPUTER
- FUNCTION MARK
