58
A p p e n d i x
Projected Image Sizes
NOTE: Use the tables to help you
determine projected image sizes.
NOTE: Visit our website at
www.infocus.com for an interactive
image size calculator. It is located
in the Technical Library in the
Service and Support section.
Table 4:
Diagonal Image Size and Width at Maximum and Minimum Distance
to Screen-Short Throw Lens
Diagonal
Image Size
(inches)
Distance to screen
Image Width
(inches)
Maximum
distance
(feet)
Minimum
Distance
(feet)
300 240 33 28
240 192 27 22
180 144 20 17
144 115 16 13
120 96 13 11
96 77 11 9
72 58 8 7
60 48 7 6
48 38 5 4
Table 5:
Diagonal Image Size and Width at Maximum and Minimum Distance
to Screen-Long Throw Lens
Diagonal
Image Size
(inches)
Distance to screen
Image Width
(inches)
Maximum
distance
(feet)
Minimum
Distance
(feet)
300 240 86 51
240 192 69 41
180 144 52 31
144 115 41 24
120 96 34 20
96 77 28 16
72 58 21 12
60 48 17 10
48 38 14 8
