PARTS LIST
KEY NO. DESCRIPTION QUANTITY
1 Rear Upright Beam 2
2 M10 x 2 3/8” Hex Bolt 5
3
∅
¾” Washer 16
4 M10 Aircraft Nut 8
5 1 5/8” x 3 1/8” Square End Cap 6
6 1 ¼” Square End Cap 2
7 Bracket 2
8 3” Short Lock Pin 1
9
∅
1” Round End Cap 7
10 Backrest Adjustment Bar 1
11 Bar Catch Panel 2
12
∅
¾” Bar Catch End Cap 2
13 Right Bar Catch 1
14 Left Bar Catch 1
15 Cross Brace 1
16 Backrest Support 2
17 1” Square End Cap 2
18 Backrest Board 1
19 Seat 1
20 M8 x 5/8” Hex Bolt 3
21
∅
5/8” Washer 5
22 Arm Curl Stand 1
23 Arm Curl Pad 1
24 Handle Grip 2
25 Lat Bar 1
26 Hook 2
27 Cable 1
28 Pulley 1
29 Pulley Bushing 2
30 1 ½” Square End Cap 4
31 Lat Bar Frame 1
32 M10 x 2 1/8” Hex Bolt 1
33 Weight Holder 1
34 Spring Clip 4
35 Sleeve 3
36
∅
1” Foam Roll End Cap 4
37 Foam Roll 4
38 Leg Developer 1
39 Foam Roll Tube 2
40 Plastic Bushing 2
41 1 ¾” Square End Cap 2
42 Front Stabilizer 1
43 Diagonal Support 1
44 Hex Socket Axle 1
45 Hex Socket Screw 1
46 M10 x ¾” Hex Bolt 2
47 Knob Bolt 1
48 M8 x 2 1/8” Hex Bolt 1
49 M8 Aircraft Nut 1
50 M6 x 1 3/8” Hex Bolt 8
51
∅
½” Washer 8
52 Main Seat Support 1
53 6 ½” Long Lock Pin 1
54 Weight Bar 1
55 Weight Plate 25# 2
56 Weight Plate 15# 2
57 Weight Plate 10# 2
