Appendix

54

LitePro 560/570 User’s Guide

Cable Connector Pin Assignments

The Y-shaped LitePro cable that shipped with your LitePro has three
connectors, they are labeled “Monitor”, “Computer” and “LCD.” The
pin assignments for these connectors are listed here.

“LCD” Connector

The end of the LitePro cable that plugs into the LitePro itself is a male
26-pin D-style connector. The table below lists its pin assignments.

Input Pin

Signal Description

Output Pin

1

Vertical sync

10

2

Horizontal sync

11

8

Blue analog

14

6

reserved

12

7

reserved

13

9

Red analog

15

16

reserved

3

17

reserved

4

18

Green analog

5

20

GND

21

GND

22

GND

23

Digital/analog video cable ID

24

GND

25

VGA/no video cable ID pin
