SECTION 4
MAINTENANCE
Figure 4-4
Figure 4-5
Figure 4-6
Figure 4-7
5. Lift other side of conveyor and push toward other
side.
6. Remove conveyor as shown.
CAUTION
Be careful no to bump the drive sprocket while
handling the conveyor, to avoid damaging the
drive shaft.
