Page 47

AQ212 Technical Specifications

TYPE

Compact, dual driver, low profile, vented sub-bass

FREQUENCY
RESPONSE (1)

48Hz-150Hz ± 3dB

DRIVERS

2 x 12” (300mm)/3” (75mm) voice coil LF drivers

RATED POWER (2)

800W AES, 3200W peak

RECOMMENDED AMPLIFIER

400-1200W into 4 ohms

SENSITIVITY (6), (3)

99dB (open space), 105dB (half space)

MAXIMUM SPL (calculated @ 1m)

123dB continuous, 129dB peak (open space)
129dB continuous, 135dB peak (half space)

NOMINAL IMPEDANCE

4 ohms

CROSSOVER

120Hz active (via AQX controller)

ENCLOSURE

100 litre, braced 18mm MDF

FINISH

Textured light grey paint

PROTECTIVE GRILLE

Light grey perforated steel

CONNECTORS

Low profile 20 amp push-lock

FITTINGS
OPTIONS

Passive low pass filter

DIMENSIONS

(W) 860mm x (H) 385mm x (D) 437mm
(W) 33.9ins x (H) 15.2ins x (D) 17.2ins

WEIGHT 39kg

(86lbs)
