16. Loudspeaker dimensions and specifications
AQ5 Technical Specifications
TYPE Ultra-compact, Dual ICT , wide dispersion vented trapezoid
FREQUENCY RESPONSE (1) 120Hz-20kHz ± 3dB
DRIVERS 2 x 5.25” (130mm) ICT  full-range drivers
RATED POWER (2) 75W AES, 300W peak
RECOMMENDED
AMPLIFIER 75-150W into 4 ohms
SENSITIVITY (6) 91dB
MAXIMUM SPL (7) 109dB continuous, 115dB peak
NOMINAL IMPEDANCE Externally switchable 4 or 16 ohms
DISPERSION (-6dB) 120º horizontal, 60º vertical
CROSSOVER ICT 
ENCLOSURE 5 litre, structural foamed ABS
FINISH Textured light grey paint
PROTECTIVE GRILLE Light grey perforated steel
CONNECTORS Low profile 12 amp push-lock
FITTINGS 4 x M6 inserts for bracket
1 x M6 insert for safety point
OPTIONS 30W 100/70V line transformer
DIMENSIONS (W) 282mm x (H) 172mm x (D) 180mm
(W) 11.1ins x (H) 6.8ins x (D) 7.1ins
WEIGHT 3.5kg (8lbs)
All material © 2007. Martin Audio Ltd. Subject to change without notice.
