CS265

Ultra-compact sub-bass

features

!

Contractor Series dedicated sub-bass

!

Low profile, ultra-compact enclosure

!

Twin 6.5" (165mm) drivers

!

Brackets for wall/ceiling mounting

applications

!

Background music playback in clubs and bars

!

AV presentations

!

Retail stores

Century Point, Halifax Road, Cressex Business Park,
High Wycombe, Buckinghamshire HP12 3SL, England.
Telephone: +44 (0)1494 535312 Facsimile: +44 (0)1494 438669
E-mail: [email protected]
All information is Copyright © 2003 Martin Audio Ltd.

A powerful sub-bass complements the versatile Contractor
Series. The ultra-compact sub provides extended low frequency,
delivering acoustic warmth and impact in commercial
environments where music is an important factor in creating the
right image and atmosphere. Primary applications are retail
stores, restaurants, hotels and audio visual suites.

architectual

www.martin-audio.com

overall dimensions

technical specifications

TYPE

Low profile, ultra-compact sub-bass system

FREQUENCY RESPONSE (1) 60Hz-120Hz ± 3dB

55Hz @ -10dB

DRIVERS

2 x 6.5" (165mm) long excursion drivers

RATED POWER (2)

200W AES, 800W peak (2 x 100W AES, 400W
peak per driver)

RECOMMENDED AMPLIFIER 100-200W into 4 ohms
SENSITIVITY (3)

93dB

MAXIMUM SPL (4)

112dB continuous, 118dB peak

NOMINAL IMPEDANCE

8 ohms per driver

DISPERSION (-6dB)

-

CROSSOVER

120Hz internal passive low pass filter

ENCLOSURE

44 litre, particle board construction

FINISH

Textured black paint

PROTECTIVE GRILLE

-

CONNECTORS

Separate binding post input connectors for each
driver including output connectors for
C115 and C516 loudspeakers

FITTINGS

-

DIMENSIONS

(W) 215mm x (H) 456mm x (D) 605mm
(W) 8.5ins x (H) 18ins x (D) 23.8ins

WEIGHT

17.5kg (38.5lbs)
