AQ210 Technical Specifications

TYPE

Ultra-compact, dual driver, low profile, vented sub-
bass

FREQUENCY
RESPONSE (1)

50Hz-150Hz ± 3dB

DRIVERS

2 x 10” (250mm)/3” (75mm) voice coil LF drivers

RATED POWER (2)

600W AES, 2400W peak

RECOMMENDED AMPLIFIER

400-800W into 4 ohms

SENSITIVITY (6), (3)

98dB (open space), 104dB (half space)

MAXIMUM SPL (calculated @ 1m)

122dB continuous, 128dB peak (open space)
128dB continuous, 134dB peak (half space)

NOMINAL IMPEDANCE

4 ohms

CROSSOVER

120Hz active (via AQX controller)

ENCLOSURE

60 litre, braced 18mm MDF

FINISH

Textured light grey paint

PROTECTIVE GRILLE

Light grey perforated steel

CONNECTORS

Low profile 20 amp push-lock

FITTINGS
OPTIONS

Passive low pass filter

DIMENSIONS

(W) 670mm x (H) 335mm x (D) 437mm
(W) 26.4ins x (H) 13.2ins x (D) 17.2ins

WEIGHT 30kg

(66lbs)
