AQ15 Technical Specifications

TYPE

Compact, two-way passive, vented trapezoid

FREQUENCY RESPONSE (1)

55Hz-18kHz ± 3dB

DRIVERS

15” (380mm) bass driver
1.4” (35mm) exit HF compression driver

RATED POWER (2)

400W AES, 1600W peak

RECOMMENDED
AMPLIFIER

400-1000W into 4 ohms

SENSITIVITY (6)

99dB

MAXIMUM SPL (7)

123dB continuous, 129dB peak

NOMINAL IMPEDANCE

8 ohms

DISPERSION (-6dB)

80º horizontal, 50º vertical

CROSSOVER 1.6kHz

passive

ENCLOSURE

63 litre, braced 18/24mm MDF

FINISH

Textured light grey paint

PROTECTIVE GRILLE

Light grey perforated steel

CONNECTORS

Low profile 20 amp push-lock

FITTINGS

12 x M8 inserts for flyware

OPTIONS

150W 100/70V line transformer

DIMENSIONS

(W) 469mm x (H) 690mm x (D) 415mm
(W) 18.5ins x (H) 27.2ins x (D) 16.4ins

WEIGHT 33.5kg

(74lbs)
