QP-402H CENTRIFUGAL PUMP — OPERATION AND PARTS MANUAL— REV. #1 (04/02/08) — PAGE 47
NOTE GX240K1PMTNH1: Model QP-402H S/N 402H-0417 AND BELOW
◊◊◊◊◊ GX240U1PMTNH1: Model QP-402H S/N 402H-0418 AND ABOVE
HONDA GX240K1PMT2/GX240U1PMT2 ENG. — CYLINDER BARREL ASSY.
CYLINDER BARREL ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 15510ZE2043 SWITCH ASSEMBLY, OIL LEVEL 1
2 957010601200 BOLT, FLANGE 6X12 2
3 9405010000 NUT, FLANGE 10MM 1
4 91353671004 O-RING, 14MM (NOK) 1
5 32197ZE2003 SUB HARNESS ......................................... 1 .......... S/N 3566259 AND BELOW
6 90013883000 BOLT, FLANGE 6X12 CT200 ..................... 1 .......... S/N 3566259 AND BELOW
7 90446KE1000 WASHER 8.21X17X0.8 1
8 9425110000 PIN, LOCK 10MM 1
9 16541ZE2010 SHAFT, GOVERNOR ARM 1
10 90013883000 BOLT, FLANGE 6X12 (CT200) 1
11 34150ZH7003 ALERT UNIT, OIL 1
12 90131883000 BOLT, DRAIN PLUG 12X15 2
13 9410912000 WASHER, DRAIN PLUG 12MM 2
14 12000ZE2815 CYLINDER BARREL ASSY., ALERT ........ 1 .......... INCLUDES ITEMS W/#
14
◊◊◊◊◊
12000ZE2406 CYLINDER BARREL ASSY., ALERT ............ 1 ........... INCULDES ITEMS W/#
15 # 91201890003 OIL SEAL 30X46X8
