QP-402H CENTRIFUGAL PUMP — OPERATION AND PARTS MANUAL— REV. #1 (04/02/08) — PAGE 37
HONDA GX240K1PMT2/GX240U1PMT2 ENG. — CARBURETOR ASSY.
CARBURETOR ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 16010ZE2812 CARBURETOR, GASKET SET .............. 1 ......... INCLUDES ITEM W/ +
2 $%# 16011ZA0931 VALVE SET, FLOAT 1
3 $%# 16013ZA0931 FLOAT SET 1
4 $ 16015ZE2005 CHAMBER SET, FLOAT ......................... 1 ......... INCLUDES ITEM 4A
................................................................................. INCLUDES ITEM W/>
....................................................................... S/N BE70B A AND BELOW
4 % 16015ZE8005 CHAMBER SET, FLOAT ......................... 1 ......... INCLUDES ITEM 4A
................................................................................. INCLUDES ITEM W/>
................................................................................. S/N BE70B B AND ABOVE
4
◊◊◊◊◊
# 16015ZE8005 CHAMBER SET, FLOAT ......................... 1 ......... INCLUDES ITEM 4A
................................................................................. INCLUDES ITEM W/>
4A + GASKET, CHAMBER SET, FLOAT .......... 1 ......... NOT SOLD SEPARATELY
5 $%# 16016ZH7W01 SCREW SET, PILOT 1
6 $%#> 16024ZE1811 SCREW SET, DRAIN .............................. 1 ......... INCLUDES ITEM 6A
6A+ GASKET, SCREW SET, DRAIN ............. 1 ......... NOT SOLD SEPARATELY
7 $%# 16028ZE0005 SCREW SET .......................................... 1 ......... INCLUDES ITEM 7A
7 A + GASKET, SCREW SET .......................... 1 ......... NOT SOLD SEPARATELY
8 $%# 16044ZE2005 CHOKE SET 1
9 16100ZE2W70 CARBURETOR ASSY., BE70B A ........... 1 ......... INCLUDES ITEMS W/$
................................................................................. S/N 3453330 AND BELOW
9 16100ZE2W71 CARBURETOR ASSY, BE70B B/C ......... 1 ......... INCLUDES ITEMS W/%
................................................................................. S/N 3453331 AND ABOVE
9
◊◊◊◊◊
16100ZE2W71 CARBURETOR ASSY, BE70B B ............ 1 ......... INCLUDES ITEMS W/#
10 $%# 16124ZE0005 SCREW, THROTTLE STOP 1
11 $%# 16166ZE2W70 NOZZLE, MAIN 1
12 $%# 16172ZE3W10 COLLAR, SET 1
13 $%# + 16173001004 GASKET, FUEL STRAINER CUP 1
14 16211ZE2000 INSULATOR, CARBURETOR 1
NOTE
GX240K1PMTNH1: Model QP-402H S/N 402H-0417 AND BELOW
◊◊◊◊◊ GX240U1PMTNH1: Model QP-402H S/N 402H-0418 AND ABOVE
