QP-402H CENTRIFUGAL PUMP — OPERATION AND PARTS MANUAL— REV. #1 (04/02/08) — PAGE 35
CAMSHAFT ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 14100ZE2W00 CAMSHAFT ASSEMBLY ..................................... 1 ......... INCLUDES ITEM W/#
1 14100ZE2W01 CAMSHAFT ASSEMBLY ..................................... 1 ......... INCLUDES ITEM W/#
1
◊◊◊◊◊
14100ZE2W01 CAMSHAFT ASSEMBLY ..................................... 1 ......... INCLUDES ITEM W/#
2 14410ZE2013 ROD, PUSH 2
3 14431ZE2010 ARM, VALVE ROCKER 2
4 14441ZE2000 LIFTER, VALVE 2
5 14451ZE1013 PIVOT, ROCKER ARM 2
6 # 14568ZE1000 SPRING, WEIGHT RETURN 1
7 14711ZE2000 VALVE, INTAKE 1
8 14721ZE2000 VALVE, EXHAUST 1
9 14751ZE2003 SPRING, VALVE 2
10 14771ZE2000 RETAINER, INTAKE VALVE SPRING 1
11 14773ZE2000 RETAINER, EXHAUST VALVE SPRING 1
12 14781ZE2000 ROTATOR, VALVE 1
13 14791ZE2010 PLATE, PUSH ROD GUIDE 1
14 90012ZE0010 BOLT, PIVOT 8MM 2
15 90206ZE1000 NUT, PIVOT ADJ. 2
16
◊◊◊◊◊
14775ZE2010 SEAT, VALVE SPRING 1
17 12209ZE8003 SEAL, VALVE STEM ........................................... 1 ......... S/N 4081305 AND ABOVE
17
◊◊◊◊◊
12209ZE8003 SEAL, VALVE STEM 1
HONDA GX240K1PMT2/GX240U1PMT2 ENG. — CAMSHAFT ASSY.
NOTE GX240K1PMTNH1: Model QP-402H S/N 402H-0417 AND BELOW
◊◊◊◊◊ GX240U1PMTNH1: Model QP-402H S/N 402H-0418 AND ABOVE
