STEP 3

Low Current Audio Outlet (Switched) Hookup

NOTE
Because certain components don’t need continuous power, or shouldn’t be turned on continuously,
these outlets are "switched." This means the components plugged into these outlets won’t receive power or shut
down unless your PowerCenter is turned on or off. You can plug any type of low current audio component
(e.g., portable cassette player) or video component (e.g., camcorder) into the pre-amp or tape outlets.

A) Attach a Monster Power

®

ID label to each component’s power cord before you plug it into the appropriate

color-coded PowerCenter outlet.

B) PRE-AMP/PROCESSOR: Plug the processor’s power cord into the HTS 2600’s corresponding

PRE-AMP/PROCESSOR outlet.

C) TAPE: Plug your tape deck’s power cord into the corresponding TAPE outlet.
