The ac generator power curve
shows the generator power avail-
able in amperes at the receptacles.
4-5. Generator Power Curve
0
50
100
150
200
250
300
0
10
20
30
40
50
60
70
80
90
AC AMPERES
AC VOL
TS
216
10,000 watts
Duty cycle is the percentage of 10
minutes that unit can weld at rated
load without overheating.
Y Exceeding duty cycle can
damage unit and void
warranty.
.
AC output is not available on all
models.
100% Duty Cycle at 280 Amperes DC
Continuous Welding
4-6. Duty Cycle
100
150
200
250
300
350
0
10
20
30
40
50
60
70
80
90
100
AC WELD
MIG/FCAW
WELDING AMPERES
% DUTY CYCLE
STICK
