Models SRC20ZJX-S, 25ZJX-S, 35ZJX-S
L2
Intake
Outlet
Intake L3
L1
Minimum installation space
Service
space
( )
L4
L2
L3
L4
L1
100
100
250
Open
Ｉ Ｉ Ｉ
Open
250
80
280
Ｉ ＩＩ
280
Open
80
75
Examples of
Dimensions
installation ＩＶ
180
Open
80
Open
Notes
（ 1） It must not be surrounded by walls on the four sides.
（ 2） The unit must be fixed with anchor bolts. An anchor bolt must not
protrude more the 15mm.
（
3） Where the unit is subject to strong winds, lay it in such
a direction that the blower outlet faces perpendicularly
to the dominant wind direction.
（
4） Leave 1m or more space above the unit.
（ 5） A wall in front of the blower outlet must not exceed the units height.
（ 6） The model name label is attached on the lower right corner of the front panel.
φ 9.52（3／8"）（Flare）
Content
C Pipe／cable draw-out hole
E Anchor bolt hole
Drain discharge hole
Symbol
B
A Service valve connection（gas side）
M10 × 4places
φ 20 × 2places
Service valve connection（liquid side） φ 6.35（1／4"）（Flare）
D
40°
40°
138.4 33.5
Terminal block
C
B
A 97.7
42.5
15.8
595
63.4
390.6
390.6
69.4
111.6 510 158.4
780 61.9
17.9
14.8
312.5
24.3
351.6
50.6
12
290
E
D
Unit:mm
