SDS-PLUS ACCESSORIES
Diameter
mm
Working
length
mm
Overall length
mm
Packing unit
Order
no.
Packed loosely
4
50
110
10
6.25230
5
50
110
10
6.25231
5
100
160
10
6.25232
6
50
110
10
6.25233
6
100
160
10
6.25234
6
150
210
10
6.25235
8
50
110
10
6.25236
8
100
160
10
6.25237
8
150
210
10
6.25238
10
50
110
10
6.25239
10
100
160
10
6.25240
10
150
210
10
6.25241
10
200
260
10
6.25242
12
100
160
10
6.25243
12
150
210
10
6.25244
12
200
260
10
6.25245
14
100
160
10
6.25246
14
150
210
10
6.25247
14
200
260
10
6.25248
Hard metal hammer drill bit, SDS-plus, 2 cutting edges
The slim, chisel-shaped bit head enables fast penetration into the
material to be drilled
The continuous core reinforcement ensures stability
and durability. It enables maximum energy transmission
from rotary hammer to drill tip.
Friction and vibration are reduced and user and machine
are relieved by the narrow back spacers
State-of-the-art thermal treatment and surface sealing by
shot-blasting ensure the prevention of wear on surfaces
and make the drill bit resistant against bending
For use in concrete, masonry, natural stone
Diameter
mm
Working
length
mm
Overall length
mm
Packing unit
Order
no.
18
150
200
1
6.30533
18
250
300
1
6.31806
18
400
450
1
6.30589
18
550
600
1
6.31807
18
950
1.000
1
6.31808
19
150
200
1
6.30534
19
400
450
1
6.30535
20
150
200
1
6.30536
20
250
300
1
6.30590
20
400
450
1
6.30537
20
550
600
1
6.31809
20
950
1.000
1
6.31810
22
200
250
1
6.30538
22
400
450
1
6.30539
22
550
600
1
6.31811
22
950
1.000
1
6.31812
23
200
250
1
6.31813
24
200
250
1
6.30540
24
400
450
1
6.30541
25
200
250
1
6.31814
25
400
450
1
6.30549
25
550
600
1
6.31815
25
950
1.000
1
6.31816
26
200
250
1
6.30542
26
400
450
1
6.30548
Hard metal hammer drill bit, SDS-plus, 4 cutting edges
Symmetrical construction of the head with main and auxiliary
cutters ensures centric guiding in the drill hole and reduces friction,
meaning longer life for the drill
Quick boring dust discharge through short spiral inlets and large
boring dust grooves of optimised double delivery helix
The 4-cutter geometry protects the drill bit on contacting iron
reinforcement and helps prevent damage to the bit head
For use in concrete, masonry, natural stone
Diameter
mm
Working
length
mm
Overall length
mm
Packing unit
Order
no.
16
200
250
1
6.31701
16
400
450
1
6.31702
18
200
250
1
6.31703
18
400
450
1
6.31704
20
200
250
1
6.31705
20
400
450
1
6.31706
22
400
450
1
6.31707
24
200
250
1
6.31708
24
400
450
1
6.31709
25
400
450
1
6.31710
28
400
450
1
6.31711
30
400
450
1
6.31712
32
400
450
1
6.31713
Hard metal hammer drill bit, SDS-plus, pro 4
Order
no.
4-piece, in small plastic case
Ø 5, 6, 8,10 mm,
L = 110/160 mm
6.30580
5-piece, in small plastic case
Ø 5, 6, 6, 8, 10 mm,
L = 160 mm
6.30581
7-piece, in small metal case
Ø 5, 6, 6, 8, 8, 10, 12 mm,
L = 110/160/165 mm
6.30584
5-piece, combo plastic case
Ø 6, 8, 10 mm hammer drill bit,
pointed chisel (6.31421),
flat chisel (6.31420)
6.30599
