SDS-PLUS ACCESSORIES
FOR HAMMERS WITH SDS-PLUS BIT RETAINER
Hard metal hammer drill bit, SDS-plus, pro 4, 2 cutting edges
Latest generation carbide: long tool life, quicker, no problem when
cutting on steel reinforcements.
The new cutting geometry on the chisel-shaped bit head ensures
quick penetration in the toughest concrete and in granite. Easy
centring.
The new 4-spiral helix with its large geometry ensures quick
delivery of bore dust, reduces friction in drill hole, improves
the vibration behaviour.
For use in concrete, masonry, natural stone
Diameter
mm
Working
length
mm
Overall length
mm
Packing unit
Order
no.
Self-service packaging
4
50
110
1
6.31780
5
50
110
1
6.31820
5
80
140
1
6.30511
5
100
160
1
6.31821
5
150
210
1
6.31864
5,5
50
110
1
6.31822
5,5
100
160
1
6.31823
6
50
110
1
6.31824
6
100
160
1
6.31825
6
150
210
1
6.31826
6
200
260
1
6.31866
6,5
50
110
1
6.31827
6,5
100
160
1
6.31828
6,5
150
210
1
6.31879
6,5
200
260
1
6.31876
6,5
250
310
1
6.31868
6,5
350
400
1
6.31785
7
50
110
1
6.31829
7
100
160
1
6.31830
7
150
210
1
6.31831
8
50
110
1
6.31832
8
100
160
1
6.31833
8
150
210
1
6.31834
Diameter
mm
Working
length
mm
Overall length
mm
Packing unit
Order
no.
8
200
260
1
6.31835
8
250
310
1
6.25229
8
400
460
1
6.31788
8
550
600
1
6.31789
9
150
210
1
6.31836
10
50
110
1
6.31837
10
100
160
1
6.31838
10
150
210
1
6.31839
10
200
260
1
6.31840
10
250
310
1
6.31841
10
400
450
1
6.30519
10
550
600
1
6.31793
10
950
1.000
1
6.31794
11
100
160
1
6.31842
11
200
260
1
6.31843
12
100
160
1
6.31844
12
150
210
1
6.31845
12
200
260
1
6.31846
12
410
450
1
6.30526
12
550
600
1
6.30527
12
950
1.000
1
6.31797
13
100
160
1
6.31847
13
200
260
1
6.31848
14
100
160
1
6.31849
14
150
210
1
6.31850
14
200
260
1
6.31851
14
250
310
1
6.31852
14
400
450
1
6.31801
14
550
600
1
6.30528
14
950
1.000
1
6.31802
15
200
260
1
6.31853
15
400
450
1
6.31803
16
100
160
1
6.31854
16
150
210
1
6.31855
16
250
310
1
6.31856
16
400
450
1
6.30531
16
550
600
1
6.30532
16
750
800
1
6.31804
16
950
1.000
1
6.31805
Other tools with SDS-plus shank end
with UHE 22 Multi,
UHE 28 Multi,
KHE 26,
KHE 26 Contact,
KHE 28 and KHE 32
for hammer drill bits with ratio thread
Tools for non-impact work
Carbide hammer drill bit
with SDS-plus shank end
ᕃ + ᕄ
ᕅ
ᕆ
ᕇ
ᕈ
ᕉ
ᕊ
ᕋ
ᕍᕗ
Tools for screw-driving
ᕍᕚ or ᕍᕛ
BHA 18, KHA 24, P´ 7911, UHE 22 Multi, UHE 28 Multi, BHE 20 Compact, BHE 20 IDR, BHE 22, BHE 24, BHE 26, KHE 26, KHE 26 Contact,
KHE 28 and KHE 32
ᕍᕘ
ᕍᕝ
ᕍᕜ
ᕍᕠ
ᕍᕞ
ᕎᕠ
ᕍᕟ
with
BHE 22,
BHE 24,
BHE 26
