C M L 1 2 S D P 2 5 6 0 7 / 1 7 / 0 2
11
This vector initialization should remain after debug when auto start will be applied for
launching the user's application. Note that the user interrupt service routines must be located
in the $4000 - $7FFF address range for correct operation. See Autostart for more details.
MON12 and NOICE Memory Map
ADDRESS TYPE MEMORY MEMORY APPLICATION
$C000 -
$FFFF
FLASH MON12, NOICE, and Utility firmware located in internal
flash, Page $3F.
$8000 -
$BFFF
External Ram User Paged Program Memory space, pages $20 - $2E.
Note: Pages $30 - $3F reside in the internal flash.
$4000 -
$7FFF
External Ram User Program Memory, emulate fixed page $3E.
$3F8C -
$3FFD
Internal Ram Ram Interrupt Vector Table
$3E00 -
$3F8B
Internal Ram Monitor reserved ram memory. Stacks and variables.
$1000 -
$3DFF
Internal Ram User Internal Ram memory
$0400 -
$0FEB
Internal EEprom User EEprom memory, Monitor reserves $FEC - $FEF for
Autostart, user should avoid $FF0 - $FFF memory use.
$0000 -
$03FF
HCS12
Registers
Monitor or user access to control registers.
NOICE OPERATION
NOICE is a development software provided by www.NOICEdebugger.com. NOICE provides a
development environment that is supported by the NOICE host PC software. This
development environment has the capability to provide symbolic debug for C source codes
and compilers for a low cost. A fully functional software version is available on the support
CD that will operate in demonstration mode. The user should register the software and
download the latest version from the above web site to get full support. See the NOICE
documentation for details.
