Multiquip Portable Generator (Honda GX160 Gasoline Engine) GAC2.2H - Manual (Page 35)

gac2.2H 60 Hz geNeRaTOR • OpeRaTiON aNd paRTs maNual — Rev. #1 (03/31/10) — page 35
NO. paRT NO. paRT Name QTY. RemaRKs
1 7931000203 ROTOR ASSY. 1
1-1 7681080003 FIELD COIL 1
1-2 0601823213 RECTIFIER 2
0601822637 SURGE ABSSORBER 2
1-3 0603000040 BEARING 1
2 7681017104 SET BOLT, ROTOR 1
3 0801086004 SET WASHER, BEARING 1
4 0040008000 WASHER, LOCK 1
5 A2136000503 ARMATURE ASSY. 1
6 7931315002 END BRACKET 1
7 7931315102 END BRACKET 1
8 7875021523 GUIDE PANEL, AIR 1
9 7681331003 COVER 1
10 7681344204 SET BOLT, STATOR 4
11 0040006000 WASHER, LOCK 4
12 0041206000 WASHER, FLAT 4
13 7871329514 GROMMET 1
14 0601851760 CAP 1
15 0017408020 HEX. HEAD BOLT 4
16 7935420104 STAY, MUFFLER 1
17 0021806010 MACHINE SCREW 2
18 7935420004 STAY, MUFFLER 1
19 0207206000 HEX. NUT 2
20 0017108020 HEX. HEAD BOLT 1
generatOr assy.
