18 58D6002
VF20 INSTALLING LOGS ON GRATE
(See Figure 15)
1. Install back log (#1) on back of burner assembly.
2. Install front log (#2) on 2 pegs on burner assembly.
ROCk WOOL INSTALLATION (VF30 UNITS ONLY)
Figure 16 - Rock Wool Installation
1. Break rock wool into dime-sized pieces.
➞
2. Place rock evenly across rock wool tray and front burner as
shown in Figure 16.
• Rock wool depth must not be more than 1".
• Do not place rock wool past the bend in rock wool tray.
• Do not place rock wool on rear burner.
Rock Wood
Tray
Rock Wool
Bend in Rock
Wool Tray
LOG PLACEMENT
Figure 15 - Installing Logs to Grate (VF20)
W
ARNING
Rock wool must be placed
correctly. Placing rock wool
in wrong area will create high
carbon monoxide.
