5-132 Maxtor Atlas 10K V
Table 5-173
Sense-Key Specific Field Contents
The data format of the Field Pointer bytes associated with the ILLEGAL REQUEST
sense key is shown in Table 5-174; the description of the data is in Table 5-175.
Table 5-174
ILLEGAL REQUEST Sense Key Field Pointer Bytes\Data Format
0x0B
Aborted Cmd
0x00 0x00 Aborted.
0x0E 0x01 Abort: IU too short (data frame with length = 0)
0x1B 0x00 Abort: Synchronous transfers timeout
0x25 0x00 Aborted with invalid LUN
0x3F 0x0F Aborted: Echo buffer overwritten
0x43 0x00 Abort: Message reject error
0x45 0x00 Abort: Reselection failed
0x47 0x00 Abort: Bus parity error
0x47 0x01 Abort: pCRC error detected
0x47 0x02 Abort: Bus parity error during ST data phase
0x47 0x03 Abort: Information Unit CRC error
0x47 0x04 Abort: Async Protection error
0x48 0x00 Abort: Initiator detected error
0x49 0x00 Aborted with invalid Message
0x4B 0x02 Abort: Too much write data received
0x4B 0x03 Abort: ACK/NAK timeout
0x4B 0x04 Abort: NAK received
0x4B 0x05 Abort: Data offset error
0x4E 0x00 Overlapped commands attempted
0x84 0x00 Aborted b/c of internal TO in DER for cur cmd
0x0E 0x1D 0x00 Data miscompare error
Sense Key
Field
Contents
Initiator Interpretation
ILLEGAL
REQUEST
Field pointer
bytes
(Table 5-174)
Illegal field's offset (in the Command Descriptor Block or data-out
buffer transfer parameters).
NOT READY
Progress Indica-
tion
(Table 5-176)
Indicates progress of FORMAT UNIT Command.
RECOV-
ERED
ERROR
Retry count
(Table 5-178)
Number of retries for I/O operation
MEDIUM
ERROR
Retry count
(Table 5-178)
Number of retries for I/O operation
Bit
Byte
7 6 5 4 3 2 1 0
15 SKSV =
1
C/D Reserved BPV Bit Pointer
Sense
Key
Sense
Code
Sense
Qualifier
Meaning
