ENGLISH REAR PANEL CONNECTIONS
(SEE PAGE iii.)
All connections to the rear panel should be made with the entire
system powered off.
To avoid errors, it is advisable to connect one cable at a time between
the various components.
a FM antenna terminal (75 ohms)
Connect an external FM antenna with a coaxial cable, or a cable
network FM source.
AM antenna and ground terminals
Connect the supplied AM loop antenna. Use the terminals marked
“AM” and “GND”.
The supplied AM loop antenna will provide good AM reception in most
areas.
Position the loop antenna until you hear the best reception.
s PRE OUT jacks
Jacks for Front - L/R, Center,Surround and Surround center.
Use these jacks for connection to an external power amplifier.
d SUB WOOFER output jack
Connect to the input jack(s) of the power amplifier for subwoofer
channel or powered subwoofer.
f DC control output 1 & 2
Connect a device that needs to be triggered by DC under certain
conditions (screen, power strip, etc…) Use the system setup menu (3/
3) to determine the conditions by which these jacks will be active.
Note:
This output voltage is for (status) control only, It is not sufficient for
drive capability.
g MULTI OUT jacks (Audio)
Connect to the input jacks of the amplifier used to drive the speakers
in another room (Second zone).
h Analog audio outputs for audio source
equipment
TAPE and CD-R/MD
Connect each output to the audio inputs (REC in) of your recording
equipment.
j Analog audio inputs
CD, TAPE, and CD-R/MD
Connect the audio outputs of your source components to the input
jacks on the receiver.
k Video outputs
VCR1, and DSS/VCR2
Connect each output to the video input (REC in) of your video
recording equipment.
l MULTI OUT jack (Video)
Connect to the input jack of the TV monitor in another room (Second
zone).
¡0 TV MONI. (VIDEO/S-VIDEO) output jacks
Connect the TV MONI jack to your TV’s video input (VIDEO IN) jack.
You can connect your video equipment with S-VIDEO jacks if
possible, or the composite VIDEO jacks.
You must use the same type of connection from your video player into
the receiver, and out of the receiver into your TV.
Both must be composite video or both must be S-Video. You cannot
convert a signal from one type to the other.
When you connect to S-video connections, there will be no signal
output from the composite video jacks.
¡1 COMPONENT VIDEO outputs
Connect to these outputs to the component video inputs of a video
projector or monitor. When a source connected to one of the two
component video inputs is selected the signal will be sent to these jacks.
¡2 SPEAKER SYSTEMS A terminals
FRONT Left & Right speakers output terminals
Connect to the front left & right speakers.
CENTER speaker output terminals
Connect to the center speaker.
SURROUND Left & Right speakers output terminals
Connect to the surround (rear) left & right speakers.
SURROUND Center speakers output terminals
Connect to the surround center speakers.
¡3 SPEAKER SYSTEMS B terminals
FRONT Left & Right speakers output terminals
Connect to the front left & right speakers.
Notes:
When you use the speaker systems A and B simultaneously, the
connected speakers which are impeadance 12 to 16 ohms must be
used.
¡4 7 CH INPUT jacks
Connect to the outputs of an external multichannel decoder.
¡5 DIGITAL outputs
Optical and Coaxial
Connect digital input of your digital recording equipment.
¡6 DIGITAL inputs
Dig.1,2 (Optical) and Dig. 3, 4, 5 (Coaxial)
Connect each input to the digital output of your source equipment.
Use the system setup menu to assign digital input to appropriate
source. (see page. 9)
Note :
The coaxial connections are not for AC-3 RF from the LD player, If
you want to decode this type of signal, an external demodulator
must be used.
¡7 REMOTE CONT. IN/OUT terminals
Connect to a Marantz component equipped with remote control (RC-
5) terminals.
¡8 MULTI ROOM REMOTE I/O terminals
IN : Connect to multi-room remote control device, available from
your Marantz dealer.
OUT : Connect to the Marantz component equipped with remote
control (RC-5) terminals in another room (Second zone).
¡9 Analog audio outputs for video source
equipment
VCR1, and DSS/VCR2
Connect each output to the audio inputs (REC in) of your video
recording equipment.
™0 Analog audio inputs for video source
equipment
TV, DVD, VCR1, and DSS/VCR2
Connect each input to the audio outputs of your video source
equipment.
