15

Cable Box

(Figure 3)

1. Connect the incoming cable to ANT on the

TV side panel.

NOTE: If your cable box has separate audio/video
outputs, please see Composite Video with
Audio or S-Video with Audio, page 16
(Figure 6).

Note:

If you have a digital cable box, refer to your

Digital Cable Box owner’s guide for instructions on

optimal connections to this TV.

Note: The TV side panel and connections shown here are for reference only and may vary by model.

Connecting an Antenna to a Cable Box or VCR

Antenna or Wall Outlet Cable

(Figure 4)

1. Connect the incoming cable to ANT on the TV

side panel.

NOTE: If your cable box has separate audio/video
outputs, please see Composite Video with
Audio or S-Video with Audio, page 16
(Figure 6).

Figure 4. Connecting the VCR with antennas or wall
outlet cable.

Figure 3. Connecting the cable box.

Note: See page 5 for Outdoor Antenna grounding.

��

�

�

��

��

��

��

��

��

�

�

�

�

�

�

�

��

��

��

��

�

��

��

��

��

�

��

�

�

��
